CNCF TOC Governance Structure + Elections 2020

By | Blog

The Cloud Native Computing Foundation (CNCF) has three main bodies: a Governing Board (GB) that is responsible for marketing, budget and other business oversight decisions for the CNCF, a Technical Oversight Committee (TOC) that is responsible for defining and maintaining the technical vision, and an End User Community (EUC) that is responsible for providing feedback from companies and startups to help improve the overall experience for the cloud native ecosystem. Each of these groups has its own defining role in the Foundation.

The TOC responsibilities and operations are defined in the CNCF Charter. The TOC is intended to be a resource of technical architects in the community that both guides the direction of the CNCF and acts as a resource to projects. Their role is also to help define what new projects are accepted to the CNCF.

The charter for the TOC was updated in September 2019. Below are the details of those changes.

Changes

The TOC is expanding from 9 members to 11 members; adding an additional End User seat and a new seat for non-sandbox project maintainers. The TOC will now consist of:

6 nominees from the Governing Board (GB)

2 nominees from the End User Community (up from 1)

1 nominee from the non-sandbox project maintainers (up from 0)

2 nominees from the other 9 members of the TOC

The next TOC Elections will take place in December 2019, with 3 GB-appointed TOC members up for election, as well as the new end user-appointed member and a non-sandbox project maintainer-appointed member, for a total of 5 seats. All TOC terms will be 2 years.

Nominations happen from the Governing Board

Nomination qualifications

Nomination qualifications are defined in the charter. A nominee should be a senior engineer in the scope of the CNCF, have the available bandwidth to be invested in the TOC, and be able to operate neutrally in discussions regardless of company or project affiliation.

Process

Each selecting group may nominate up to two people, and the nominee must agree to be nominated. A one-page nominating statement should include the nominee’s qualifying experience and contact information. Following the nomination, there is a two week evaluation period for the Governing Board and TOC to review and contact nominees. After the evaluation period, the Governing Board and the TOC votes on each nominee to ensure qualification, with a 50% vote to become a Qualified Nominee. We will publish the list of Qualified Nominees.

TOC Election Schedule:

5 seats available: 3 GB-appointed seats, 1 end-user appointed, 1 maintainer appointed

December 12: Nominations open – 12 PM PT

Dec 20: Nominations close (last day of business before holiday) – 12 PM PT

Jan 6: Qualification period opens

Jan 20: Qualification period closes

Jan 20: Election opens

Feb 1: Election closes

Voting occurs by a time-limited Condorcet-IRV ranking in CIVS

Feb 3: Election results posted

1 TOC appointed seat (3/18/2020 start date)

February 3rd: Nominations open – 12 PM PT

February 10: Nominations close

February 11: Qualification period opens

February 28: Qualification period closes

March 1: Election opens

March 17: Election closes

Voting occurs by a time-limited Condorcet-IRV ranking in CIVS

March 17: Election results posted

CNCF to Participate Again in the Community Bridge Mentorship Program

By | Blog

I’m happy to announce that CNCF will participate again in the Community Bridge Mentorship program. As well as Google Summer of Code and Outreachy, Community Bridge is a platform that brings an opportunity to offer paid internships and mentorships.

The current round starts in December 2019, and will continue until March 2020. We are happy to offer 5 sponsored slots for the students, who will work on the CNCF projects.

If you are a project maintainer and you’d like to have your project participating in Community Bridge, please submit a PR as described. Once the projects list will be finalized, mentees will be able to apply via the Community Bridge platform directly.

Please submit your project ideas to GitHub by December 16, 2019.

How Kubernetes Has Been ‘Transformational’ to Productivity and Culture at uSwitch

By | Blog

When it was founded in 2000, uSwitch helped consumers in the U.K. compare prices for their utilities. The company eventually expanded to include comparison and switching tools for a wide range of verticals, including broadband service, credit cards, and insurance.

Internally, those verticals translated into a decentralized technology infrastructure. Teams—which were organized around the markets their applications price-compared—ran all their own AWS infrastructure and were responsible for configuring load-balancers, EC2 instances, ECS cluster upgrades, and more.

Though many teams had converged on the idea of using containerization for web applications and deploying to ECS, “everyone was running different kinds of clusters with their own way of building and running them, with a whole bunch of different tools,” says Head of Engineering Paul Ingles. With the increasing cloud and organizational complexity, they had difficulty scaling teams. “It was just inefficient,” says Infrastructure Lead Tom Booth. “We wanted to bring some consistency to the infrastructure that we had.”

Booth and Ingles had both experimented with Kubernetes before, when the company first adopted containerization. Separately, the infrastructure team had done an evaluation of several orchestration systems, in which Kubernetes came out on top. In late 2016, the two began working on building a Kubernetes platform for uSwitch.

Today, all 36 teams at uSwitch are running at least some of their applications on the new platform, and as a result, the rate of deployments has increased almost 3x. The release rate per person per week has almost doubled, with releases now happening as often as 100 times a day. Moreover, those improvements have been sustained, even as more people were added to the platform.

Read more about uSwitch’s cloud native journey in the full case study.

Kubernetes Audit: Making Log Auditing a Viable Practice Again

By | Blog

Originally published on Alcide Blog by Nitzan Niv

In the security world, one of the most established methods to identify that a system was compromised, abused or mis-configured is to collect logs of all the activity performed by the system’s users and automated services, and to analyze these logs.

Audit Logs as a Security Best Practice

In general, audit logs are used in two ways:

  1. Proactively identifying non-compliant behavior. Based on a configured set of rules, that should faithfully filter any violation to the organization’s policies, an investigator finds in the audit log entries that prove a non-compliant activity has taken place. With automated filters, a collection of such alerts is periodically reported to compliance investigators.
  2. Reactively investigating a specific operational or security problem. The known problem is traced back to the responsible party, root causes or contributing factors by a post-mortem investigation, following deduced associations from state to causing action and previous state.

Kubernetes Audit Logs

Let us examine how audit logs are configured and used in the Kubernetes world, what valuable information they contain, and how they can be utilized to enhance the security of the Kubernetes-based data center.

The Kubernetes audit log is intended to enable the cluster administrator to forensically recover the state of the server and the series of client interactions that resulted in the current state of the data in the Kubernetes API.

In technical terms, Kubernetes audit logs are detailed descriptions of each call made to the Kubernetes API-Server. This Kubernetes component exposes the Kubernetes API to the world. It is the central touch point that is accessed by all users, automation, and components in the Kubernetes cluster. The API server implements a RESTful API over HTTP and performs all the API operations.

Upon receiving a request, the API server processes it through several steps:

  1. Authentication: establishing the identity associated with the request (a.k.a. principal). There are several mechanisms for authentication.
  2. RBAC/Authorization: The API server determines whether the identity associated with the request can access the combination of the verb and the HTTP path in the request. If the identity of the request has the appropriate role, it is allowed to proceed.
  3. Admission Control: determines whether the request is well formed and potentially applies modifications to the request before it is processed.
  4. Validation: ensures that a specific resource included in a request is valid.
  5. Perform the requested operation. The types of supported operations include:
    • Create resource (e.g. pod, namespace, user-role)
    • Delete a resource or a collection of resources
    • List resources of a specific type (e.g. pods, namespaces), or get a detailed description of a specific resource
    • Open a long-running connection to the API server, and through it to a specific resource. Such a connection is then used to stream data between the user and the resource. For example, this enables the user to open a remote shell within a running pod, or to continuously view the logs of an application that runs inside a pod.
    • Monitors a cluster resource for changes.

A request and its processing steps may be stored in the Kubernetes audit log. The API server may be configured to store all or some of these requests, with varying degrees of details. This audit policy configuration may also specify where the audit logs are stored. Analysis tools may request to receive these logs through this hook.

Challenges of Auditing a Kubernetes Cluster

While the principles of audit logs collection and analysis naturally apply to the cloud, and specifically to data centers built on Kubernetes, in practice the scale, the dynamic nature and the implied context of such environments make analyzing audit logs difficult, time consuming and expensive.

The scale of the activities in the cluster means any analysis that relies solely on manual inspection of many thousands of daily log entries is impractical. A “quiet” cluster with no human-initiated actions and no major shifts in applicative activity, is still processing thousands of API calls per hour, generated by the internal Kubernetes mechanisms that ensure that the cluster is alive, its resources are utilized according to the specified deployments, and failures are automatically identified and recovered from. Even with log filtering tools, the auditor needs a lot of experience, intuition and time to be able to zoom in on a few interesting entries.

The dynamic nature of a system like a Kubernetes cluster means that workloads are being added, removed or modified at a fast pace. It’s not a matter of an auditor focusing on access to a few specific workloads containing a database – it’s a matter of identifying which workloads contain a sensitive database at each particular instant in the audited time period, which users and roles had legitimate reason to access each of these database-workloads at what times, and so on.

Furthermore, while finding some interesting results is just a matter of finding the specific entries in the log that are known in advance to correlate to undesirable activity, finding suspicious but previously unknown activity in the logs requires a different set of tools and skills, especially if this suspicious behavior can only be understood from a wider context over a prolonged period, and not just one or two related log entries. For example, it is rather simple to detect a user’s failure to authenticate himself to the system, as each login attempt shows up as a single log entry. However, identifying a potential theft of user credentials may only be detected if the auditor connects seemingly different entries into a whole pattern, for example access to the system using a specific user’s credentials from a previously unknown Internet address outside the organization, while the same user’s credentials are used concurrently to access the system from within the organization’s network.

Making Log Auditing a Viable Practice Again

In order to make the audit of a large, complex Kubernetes cluster a viable practice, we need to adapt the auditor’s tools to this environment. Such tools would automatically and proactively identify anomalous and problematic behavior, specifically in the context of Kubernetes control security, in order to:

  1. Detect security-related abuse of Kubernetes cluster, especially behavior that can only be detected from observing extended context over multiple activities.
  2. Focus compliance investigations on Kubernetes misuses that are beyond detection by simple log filtering rules.

Of course, in order to achieve these goals, such a tool must be able to:

  1. Automatically analyze Kubernetes Audit logs, detecting anomalous behavior of users and automated service accounts and anomalous access to sensitive resources.
  2. Summarize the detected anomalies as well as important trends and statistics of the audit information for user-friendly understanding. At the end of the day, the auditor should have enough information that she can understand, qualify or ignore the results of the automatic analysis.

Let us describe some of the more complex threat scenarios that we would like the envisioned audit log analyzer to detect automatically:

  • Adversaries may steal the credentials of a specific user or service account (outside the cluster) or capture credentials earlier in their reconnaissance process through social engineering as a means of gaining initial access to cluster resources.
  • Adversaries may use token theft (inside the cluster, from compromised or legitimately accessible resources) or token impersonation to operate under a different user or service account (i.e., security context) to perform actions for lateral movement, privilege escalation, data access and data manipulation, while evading detection.
  • Adversaries may use insufficient or misconfigured RBAC to gain access under their own security context to privileged and sensitive resources (cluster’s secrets, configuration maps, authorization policies etc.) for lateral movement, privilege escalation, data access and data manipulation.
  • Adversaries may exploit vulnerabilities in Kubernetes API Server (authentication, authorization, admission control or validation requests processing phases) to gain access to privileged and sensitive resources (cluster’s secrets, configuration maps, authorization policies etc.) for initial access, lateral movement, privilege escalation, data access and data manipulation.

Obviously, detection of such scenarios is way beyond a simple filtering of the audit log using predetermined rules. Sophisticated machine learning algorithms must be used to achieve this automatically, at scale and within a reasonable time after actual threatening activity.

The analyzer tool should collect features of the operational and security activity of the cluster as they are presented in the log and feed them to the machine learning algorithm for measurement, weighting and linking together. At the end of this process, possible patterns of suspicious behavior can be presented to the auditor for validation and further investigation.

Summary

Auditing of system logs is a well-established practice to identify security threats to the system, whether before these threats have a detrimental effect on after the threat is realized. In fact, some forms of periodic audit are mandated by laws and regulations.

Nevertheless, identifying suspicious patterns in audit logs of complex, large-scale, dynamic systems like modern day Kubernetes clusters is a formidable task. While using some sort of automation is mandatory for such and analysis, most existing audit-tools are just mindless filters, hardly assisting the auditor in the deeper challenges of her task.

In this article we presented a vision for an automated Kubernetes audit log analyzer that goes far beyond that. Using machine learning, such a tool can autonomously detect potential threatening pattern in the log that the auditor can focus on, even in real time. Additionally, summarizing the information in the audit log in a way that is user-digestible lets the auditor quickly validate the identified patterns as well as helps her investigate additional hidden suspicious activities.



Case study: TiKV in JD Cloud

By | Blog

Guest post by Can Cui, Infrastructure Specialist at JD Cloud

JD Cloud, is a full-service cloud computing platform and integrated cloud service provider. Like Microsoft Azure, we deliver comprehensive cloud computing services ranging from infrastructure building and strategic consulting to business platform development and operations. By November, 2018, we had achieved technical innovation in more than 120 cloud computing products and services, exceeding 330 thousand registered users. In 2018, Forrester, the world-renowned research and advisory firm, evaluated our product capacity, strategic layout, marketing performance, and other factors, and recognized JD Cloud as a “Strong Performer.”

Our Object Storage Service (OSS) provides cloud storage services of high availability, low cost, and strong security for enterprises and individual developers. Previously, we used MySQL to store OSS metadata. But as the metadata grew rapidly, standalone MySQL couldn’t meet our storage requirements. In the future, we expect to hit 100 billion or even 1 trillion rows. We faced severe challenges in storing unprecedented amounts of data that kept soaring.

In this post, I’ll deep dive into how TiKV, an open-source distributed transactional key-value database, empowered us to manage huge amounts of OSS metadata with a simple and horizontally scalable architecture. I’ll introduce why we chose TiKV, how we’re using it, and some thoughts about future plans.

Our pain points

JD Cloud’s OSS provides a full range of products including file upload, storage, download, distribution, and online processing. We aim to offer a safe, stable, massive, and convenient object storage service for users.

In this section, I’ll elaborate on challenges we encountered in storing OSS metadata and our exploration to redesign the metadata storage system.

Challenges caused by rapid data growth

As shown in the figure below, we previously used MySQL to store OSS metadata (such as image size). Metadata was grouped in buckets, which are similar to namespaces.

Original OSS metadata storage system based on MySQL

Many similar systems use such a design. But facing business growth with metadata booming, we were plagued by the following challenges:

The number of objects in a single bucket was expected to become huge.

We anticipated that the number of objects in a single bucket would grow large, and thought hash-based sharding and scan merge could resolve this problem.

The number of objects in a single bucket unexpectedly increased rapidly.

In the early days, we had a small number of metadata. We might need only four buckets to store them. But as our business developed, the metadata surged at an unanticipated rate, so we needed to redivide the metadata into 400 buckets.

In this case, we had to rehash and rebalance data. However, the data rehashing process was very complicated and troublesome.

The storage capacity of our previous metadata storage system was limited, and this system couldn’t scale horizontally.

We hoped our metadata storage database could scale infinitely; for example, to hold 100 billion or even 1 trillion rows of data. But this wasn’t the case.

Our exploration

To conquer the difficulties mentioned above, we redesigned our metadata storage system as shown in the following figure:

Redesigning the OSS metadata storage system

The core technique of this solution was making the most data static, because static data was easy to store, migrate, and split. Every day, we made the data written on the previous day static, and merged the static data into the historical data.

However, as the following diagram reveals, this solution had two problems:

  • Data distribution was complex, so it was hard to manage.
  • Data scheduling was inflexible, which made system maintenance more difficult.

Complexity of the metadata storage system

Therefore, we began to look for a new solution: a globally ordered key-value store with great storage capacity and elastic scalability. Finally, we found TiKV, and it turns out it’s a perfect match for storing enormous amounts of data.

What is TiKV

TiKV is a distributed transactional key-value (KV) database originally created by PingCAP to complement TiDB, an open-source MySQL-compatible NewSQL Hybrid Transactional/Analytical Processing (HTAP) database.

As an incubating project of Cloud Native Computing Foundation (CNCF), TiKV is intended to fill the role of a unifying distributed storage layer. TiKV excels at working with large amounts of data by supporting petabyte-scale deployments spanning trillions of rows.

TiKV complements other CNCF project technologies like etcd, which is useful for low-volume metadata storage, and you can extend it by using stateless query layers that speak other protocols.

The TiKV architecture

The overall architecture of TiKV is illustrated in the figure below:

TiKV architecture

TiKV connect to clients. To understand how TiKV works, you need to understand some basic terms:

  • Store: A store refers to a tikv-server instance, which serves as a storage node in the cluster. There are one or more stores within each disk.
  • Region: A Region is the basic unit of data movement and is replicated by the Raft protocol. Within each store, there are many Regions. Each Region is replicated to several nodes.
  • Raft group: A Raft group consists of the replicas of the same Region on different nodes.
  • Placement Driver (PD): PD schedules the load balancing of the data among different TiKV nodes.

TiKV’s features

TiKV has the following features:

Why we chose TiKV

After we investigated many database products, we chose TiKV because it has the following advantages:

  • TiKV supports a globally-ordered key-value store, and it is easy to horizontally scale. This fulfills the requirements for metadata storage of our OSS.
  • Through rigorous tests, TiKV demonstrates excellent performance that meets the demands of our application.
  • TiKV boasts an active community, with complete documentation and ecosystem tools.
  • TiKV is a CNCF incubation-level hosted project. It iterates rapidly with features under fast development.
  • Compared with TiDB server’s code, TiKV’s code is simpler. We can further develop TiKV based on our needs.

Besides the advantages above, TiKV also passed our tests, including:

  • The feature test. We tested whether TiKV’s main features satisfied the requirements of our application.
  • The performance test. We tested whether queries per second (QPS), and the average, 90th percentile, and 99th percentile query latencies were ideal.
  • The fault injection test. Engineers specializing in data storage tend to focus more on system behavior in abnormal conditions rather than on performance status. In addition, distributed storage is more complex than standalone storage. Thus, we simulated various machine, disk, and network faults. We even randomly combined these faults and triggered abnormalities in the system to test the system behavior.
  • The staging environment test. Before we deployed TiKV to production on a large scale, we ran TiKV on some production applications that were less important. Then, we collected some issues and problems that could be optimized.

The test results showed that TiKV met our requirements for system performance and security. Then, we applied TiKV in our OSS metadata storage system, as shown in the following figure:

OSS metadata storage system based on TiKV

Migrating data from MySQL to TiKV

Many TiDB users have migrated data from MySQL to TiDB, but far fewer have migrated data to TiKV. We gained firsthand experience in data migration from MySQL to TiKV.

This section covers how we migrated data from MySQL to TiKV, including our migration policy, the traffic switch process, and how we verified data.

The data migration policy

The following figure shows our data migration policy:

Data migration policy

The key points of this policy are as follows:

  • To guarantee data security, we enabled the doublewrite buffer for all the production data.
  • We set the existing data read-only and migrated this data to TiKV. During the migrating process, the incremental data was directly written to TiKV.
  • Every day, we set the incremental data generated on the previous day to be static, and compared this data in TiKV to that in MySQL for data verification. If a doublewrite failed, we would use the data in MySQL.

Traffic switching

The whole traffic switch process consisted of three steps:

  1. Switched the existing traffic to TiKV, and verified reads.

To switch existing traffic, we made the existing data static to simplify data migration, data comparison, and rollback processes.

  1. Switched the incremental traffic to TiKV, and verified reads and writes.

To switch incremental traffic, we performed doublewrites of incremental data to TiKV and MySQL. When an abnormality occurred, we rolled back our application to MySQL. This would not affect the online application.

  1. Took MySQL offline after verifying data in TiKV.

TiKV exhibited outstanding results in the test environment. Therefore, we used TiKV as the primary database during the doublewrite process.

Data verification

During data verification, the most challenging problem was verifying incremental data, as incremental data was changing daily. Thus, we decided to doublewrite data to TiKV and MySQL, made incremental data static each day, and verified data in TiKV against that in MySQL to check whether data in TiKV was reliable (no data loss or inconsistency).

However, in this case, we might run across a problem: writing data to TiKV succeeded, but writing to MySQL failed. The two writes were executed in different transactions, so they were not necessarily both successful or unsuccessful, especially when reads and writes were frequent. Under this circumstance, we would check the operational records of the application layer to determine whether the issue was caused by TiKV or the application layer.

The application status

Currently, TiKV serves as the primary database for our OSS metadata storage application. We plan to take MySQL offline at the end of 2019.

The current application status is as follows:

  • We’ve deployed more than 10 TiKV clusters.
  • In the production environment, a single cluster’s QPS reaches 40,000 (half reads and half writes) at peak time.
  • The data volume of the largest cluster hits 20+ billion rows, and this cluster contains  500,000+ Regions.
  • The latency is about 10 milliseconds.

We are now testing TiKV 3.0, and expect to deploy it to the production environment in the fourth quarter of 2019.

What’s next

Thanks to the horizontal scalability of TiKV, we can deal with an enormous amount of OSS metadata in a storage architecture that is simpler than before.

In the future, we’ll optimize TiKV in the following ways:

  • Implement disaster recovery at the TiKV layer. Currently, we perform disaster recovery at the application layer. Later, we’ll implement disaster recovery at the TiKV layer. We also expect subsequent versions of TiKV will support this feature.
  • Optimize the cluster hardware resources. Because object metadata storage is a storage-intensive application, we want to reduce hardware costs. For example, we hope we can use larger disks (8 TB or 10 TB) or cheaper disks. We’ll work together with PingCAP engineers to optimize hardware resources.
  • Optimize the Region scheduling mechanism. Currently, TiKV’s scheduling mechanism is complicated. This is troublesome for storage-intensive applications that have a huge amount of data. We’ll optimize the Region scheduling process so that when data upsurges we don’t need to migrate data to another machine.

Chinese version: TiKV 在京东云对象存储元数据管理的实践

How Slack Leverages Vitess to Keep Up with Its Ever-Growing Storage Needs

By | Blog

If you live on Slack, multiply your usage by millions of active users worldwide and you’ll quickly understand why the company ran into data storage challenges.

In the fall of 2016, Slack was dealing with hundreds of thousands of MySQL queries per second and thousands of sharded MySQL hosts in production. The company’s busiest database hosts had to handle all the queries from larger and larger customers, so they were running hotter and hotter while there were thousands of other hosts that were mostly idle. And the burden of manually managing the fleet of hosts in the legacy configuration was taxing the operations teams.

The Slack engineering team knew it needed a new approach to scaling and managing databases for the future. The challenges were technological, architectural, as well as process-related, and they needed to be solved while the system was running at full scale.

“We have thousands of lines of code containing SQL queries, some of which expect MySQL-specific semantics,” says Principal Engineer Michael Demmer. “That plus our years of operational experience and tooling meant that we really did not want to move away from MySQL at the heart of our database systems.” The company also wanted to continue to host its own instances running in AWS, on a platform that incorporated new technology now, but could still be extensible later. “Vitess was really the only approach that fit all our needs,” says Demmer.

The team had confidence given Vitess’s success at YouTube, and after getting familiar with the code, decided to build upon the technology in order to make it work at Slack. (Everything has been upstreamed in the open source project.) It took about seven months to go from whiteboard to production. Currently, around 45% of Slack’s overall query load—about 20 billion total queries per day, with some 500,000 queries per second at peak times—is running on Vitess. And all new features are written to use Vitess only.

“Vitess has been a clear success for Slack,” says Demmer. “The project has both been more complicated and harder to do than anybody could have forecast, but at the same time Vitess has performed in its promised role a lot better than people had hoped for.” Critical application features like @-mentions, stars, reactions, user sessions, and others are now fully backed by Vitess, “powered in ways that are much more sustainable and capable of growth,” he says. Performance-wise, the connection latency with Vitess is an extra millisecond on average, not discernable to users. “Our goal is that all MySQL at Slack is run behind Vitess,” says Demmer. “There’s no other bet we’re making in terms of storage in the foreseeable future.”

Read more about Slack’s use of Vitess in the full case study.

Announcing the CNCF Job Board

By | Blog

We are excited to announce the availability of the CNCF job board, the official job board of CNCF. According to the 2018 Linux Foundation Open Source Jobs Report, containers are rapidly growing in popularity and importance, with 57% of hiring managers seeking that expertise.

The CNCF job board leverages an engaged audience of over 500 members and tens of thousands of monthly visitors to help employers find the perfect candidate. It’s free to both post and apply; CNCF member job openings get a featured listing.

The CNCF job board is the ideal way to connect with the world’s top developers and hire great people. We invite you to post your job, search for candidates or find your next opportunity through the site.

kubectl flags in your plugin

By | Blog

Originally posted by Gianluca Arbezzano on Gianarb.it

This is not at all a new topic, no hacking involved, but it is something everybody needs to know where we design kubectl plugin.

I was recently working at one and I had to make the user experience as friendly as possible compared with the kubectl, because that’s what a good developer does! Tricks other developers to make their life comfortable, if you are used to do:

$ kubectl get pod -n your-namespace -L app=http

To get pods from a particular namespace your-namemespace filtered by label app=http and your plugin does something similar or it will benefit from an interaction that remembers the classic get you should re-use those flags.

Example: design a kubectl-plugin capable of running a pprof profile against a set of containers.

My expectation will be to do something like:

$ kubectl pprof -n your-namespace -n pod-name-go-app

The Kubernetes community writes a lot of their code in Go, it means that there are a lot of libraries that you can re-use.

kubernetes/cli-runtime is a library that provides utilities to create kubectl plugins. One of their packages is called genericclioptions and as you can get from its name the goal is obvious.


// import "github.com/spf13/cobra"
// import "github.com/spf13/pflag"
// import "k8s.io/cli-runtime/pkg/genericclioptions"

// Create the set of flags for your kubect-plugin
flags := pflag.NewFlagSet("kubectl-plugin", pflag.ExitOnError)
pflag.CommandLine = flags

// Configure the genericclioptions
streams := genericclioptions.IOStreams{
    In:     os.Stdin,
    Out:    os.Stdout,
    ErrOut: os.Stderr,
}

// This set of flags is the one used for the kubectl configuration such as:
// cache-dir, cluster-name, namespace, kube-config, insecure, timeout, impersonate,
// ca-file and so on
kubeConfigFlags := genericclioptions.NewConfigFlags(false)

// It is a set of flags related to a specific resource such as: label selector
(-L), --all-namespaces, --schema and so on.
kubeResouceBuilderFlags := genericclioptions.NewResourceBuilderFlags()

var rootCmd = &cobra.Command{
    Use:   "kubectl-plugin",
    Short: "My root command",
    Run: func(cmd *cobra.Command, args []string) {
		cmd.SetOutput(streams.ErrOut)
    }
}

// You can join all this flags to your root command
flags.AddFlagSet(rootCmd.PersistentFlags())
kubeConfigFlags.AddFlags(flags)
kubeResouceBuilderFlags.AddFlags(flags)

This is the output:

$ kubectl-plugin --help
My root command

Usage:
  kubectl-plugin [flags]

Flags:
      --as string                      Username to impersonate for the operation
      --as-group stringArray           Group to impersonate for the operation, this flag can be repeated to specify multiple groups.
      --cache-dir string               Default HTTP cache directory (default "/home/gianarb/.kube/http-cache")
      --certificate-authority string   Path to a cert file for the certificate authority
      --client-certificate string      Path to a client certificate file for TLS
      --client-key string              Path to a client key file for TLS
      --cluster string                 The name of the kubeconfig cluster to use
      --context string                 The name of the kubeconfig context to use
  -f, --filename strings               identifying the resource.
  -h, --help                           help for kubectl-pprof
      --insecure-skip-tls-verify       If true, the server's certificate will not be checked for validity. This will make your HTTPS connections insecure
      --kubeconfig string              Path to the kubeconfig file to use for CLI requests.
  -n, --namespace string               If present, the namespace scope for this CLI request
  -R, --recursive                      Process the directory used in -f, --filename recursively. Useful when you want to manage related manifests organized within the same directory. (default true)
      --request-timeout string         The length of time to wait before giving up on a single server request. Non-zero values should contain a corresponding time unit (e.g. 1s, 2m, 3h). A value of zero means don't timeout requests. (default "0")
  -l, --selector string                Selector (label query) to filter on, supports '=', '==', and '!='.(e.g. -l key1=value1,key2=value2)
  -s, --server string                  The address and port of the Kubernetes API server
      --token string                   Bearer token for authentication to the API server
      --user string                    The name of the kubeconfig user to use

Kubernetes Scheduler 101

By | Blog

Originally published on Magalix Blog by Mohamed Ahmed

What is Kubernetes Scheduling?

If you’ve read any Kubernetes documentation, books, or articles you’ve undoubtedly seen the word “schedule” in phrases like “the Pod gets scheduled to the next available node” for example. Kubernetes Scheduling involves mush more than just placing a pod on a node. In this article, we discuss the different mechanisms that Kubernetes follows when it needs to deal with a new pod, and the components entailed in the process.

What happens when you create a Pod on a Kubernetes Cluster?

In a matter of seconds, the Pod is up and running on one of the cluster nodes. However, a lot has happened within those seconds. Let’s see:

  1. While scanning the API server (which it is continuously doing), the Kubernetes Scheduler detects that there is a new Pod without a nodeName parameter. The nodeName is what shows which node should be owning this Pod.
  2. The Scheduler selects a suitable node for this Pod and updates the Pod definition with the node name (though the nodeName parameter).
  3. The kubelet on the chosen node is notified that there is a pod that is pending execution.
  4. The kubelet executes the Pod, and the latter starts running on the node.

How Kubernetes Selects the Right node?

Perhaps the hardest part of the above steps is when the Scheduler decides which node it should select for running the pod. Indeed, this part takes the most work as there are several algorithms that the Scheduler must use to make this decision. Some of those algorithms depend on user-supplied options, while Kubernetes itself calculates others. They can be explained like a set of questions that the Scheduler asks the node to decide it.

Do you have what it takes to run this pod (predicate)?

A node may be overloaded with so many busy pods consuming most of its CPU and memory. So, when the scheduler has a Pod to deploy, it determines whether or not the node has the necessary resources. If a Pod was deployed to a node that does not have enough memory (for example) that the Pod is requesting, the hosted application might behave unexpectedly or even crash.

Sometimes, the user needs to make this decision on behalf of Kubernetes. Let’s say that you’ve recently purchased a couple of machines equipped with SSD disks, and you want to use them explicitly for the MongoDB part of the application. To do this, you select the nodes through the node labels in the pod definition. When a node does not match the provided label, it is not chosen for deploying the Pod.

Scheduler

As demonstrated in the above graph, the predicate decision resolves to either True (yes, deploy the pod on that node) or False (no, don’t deploy on that one).

Are you a better candidate for having this pod (priorities)?

In addition to true/false decisions a.k.a predicates, the scheduler executes some calculations (or functions) to determine which node is more suited to be hosting the pod in question.

For example, a node where the pod image is already present (like it’s been pulled before in a previous deployment) has a better chance of having the pod scheduled to it because no time will be wasted downloading the image again.

Another example is when the scheduler favors a node that does not include other pods of the same Service. This algorithm helps spread the Service pods on multiple nodes as much as possible so that one node failure does not cause the entire Service to go down. Such a decision-making method is called the spreading function.

Several decisions, like the above examples, are grouped, and weight is calculated for each node based on the final decision. The node with the highest priority wins the pod deployment.

The final decision

You may be asking, if there are so many factors that the Kubernetes Scheduler must consider before selecting a node for deploying the pod, how does it get to choose the right one?

  1. Well, the decision process is done as follows:
  2. The scheduler determines all the nodes that it knows they exist and are healthy.
  3. The scheduler runs the predicate tests to filter out nodes that are not suitable. The rest of the nodes form a group of possible nodes.
  4. The scheduler runs priority tests against the possible nodes. Candidates are ordered by their score with the highest ones on the top. At this point, the highest-scoring possible node gets chosen. But sometimes there may be more than one node with the same score.
  5. If nodes have the same score, they are moved to the final list. The Kubernetes Scheduler selects the winning node in a round-robin fashion to ensure that it equally spreads the load among the machines.

What if that was not the best decision?

In busy Kubernetes Clusters, the time between the Scheduler choosing the right node and the kubelet on that node executing the pod may be sufficient for changes to occur on the nodes. Even if that time is no more than a few milliseconds, a pod may get terminated on one of the nodes that were filtered out due to insufficient memory. That node could’ve had a higher score on the priority test only if it wasn’t overloaded back then. But now, perhaps a less-suitable node was selected for the pod.

Some projects aim at addressing this situation like the Kubernetes Descheduler Project. In this application, the pod is automatically evicted from the node if another node proved to be a better choice for pod-scheduling. The pod is returned to the schedule to deploy it again to the right node.

Perhaps a more difficult situation could occur when the opposite scenario happens. Let’s say that a node was tested against whether or not it could provide 2 GB of memory. At the time the Scheduler was doing the predicate check, the node did have some spare RAM. However, while kubelet is executing the pod against the node, a DaemonSet was deployed to the same node. This DaemonSet entailed some resource-heavy operation that consumed the remaining 2 GB. Now, when the pod tries to run, and since it is missing the amount of memory it requires to function correctly, it fails. If this pod was deployed using just a pod definition, then the application that it runs on would fail to start, and Kubernetes could do nothing about it. However, if this pod was part of a pod controller like a Deployment or a ReplicaSet, then once it fails, the controller will detect that there is a smaller number of replicas than it should be handling. Accordingly, the controller will request another pod to be scheduled. The Scheduler will run all the checks again and schedules the pod to a different node. This is one of the reasons why it is always advised to use a higher-level object like Deployments when creating pods.

User-defined decision-making

Earlier in this article, we mentioned that a user could simply choose to run a pod on a specific node using the .spec.nodeSelector parameter in the Pod definition or template. The

nodeSelector selects nodes that have specific one or more labels. However, sometimes, user

requirements get more complicated. A nodeSelector, for example, selects nodes that have all the labels defined in the parameter. What if you want to make a more flexible selection?

Node Affinity

Let’s consider our earlier example when we wanted to schedule our pod to run on the machines with the SSD disks. Let’s say that we want them also to use the eight-cored hosts. Node affinity allows for flexible decisions like this. The following pod template chooses nodes that have labels of feature=ssd or feature=eight-cores:

apiVersion: v1
kind: Pod
metadata:
 name: mongo
spec:
 affinity:
   nodeAffinity:
     requiredDuringSchedulingIgnoredDuringExecution:
       nodeSelectorTerms:
       - matchExpressions:
         - key: feature
           operator: In
           values:
           - ssd
           - eight-cores
 containers:
 - name: mongodb
   image: mogo

The requiredDuringSchedulingIgnoredDuringExecution option

There’s a new option here: requiredDuringSchedulingIgnoredDuringExecution. It’s is easier than it looks. It means that we need to run those pods only on nodes labeled feature=ssd or feature=eight-cores. We don’t want the scheduler to make decisions outside of this set of nodes. This is the same behavior as the nodeSelector but with a more expressive syntax.

The preferredDuringSchedulingIgnoredDuringExecution option

Let’s say that we’re interested in running the pod on our selected nodes. But, since launching the pod is of an absolute priority, we demand to run it even if the selected nodes are not available. In this case, we can use the preferredDuringSchedulingIgnoredDuringExecution option. This option will try to run the pod on the nodes specified by the selector. But if those nodes are not available (failed the tests), the Scheduler will try to run the pod on the next best node.

The Node Anti-Affinity

Some scenarios require that you don’t use one or more nodes except for particular pods. Think of the nodes that host your monitoring application. Those nodes shouldn’t have many resources due to the nature of their role. Thus, if other pods than those which have the monitoring app are scheduled to those nodes, they hurt monitoring and also degrades the application they are hosting. In such a case, you need to use node anti-affinity to keep pods away from a set of nodes. The following is the previous pod definition with anti-affinity added:

apiVersion: v1
kind: Pod
metadata:
 name: mongo
spec:
 affinity:
   nodeAffinity:
     requiredDuringSchedulingIgnoredDuringExecution:
       nodeSelectorTerms:
       - matchExpressions:
         - key: feature
           operator: In
           values:
           - ssd
           - eight-cores
         - key: role
           operator: NotIn
           values:
           - monitoring

 containers:
 - name: mongodb
   image: mogo

Adding another key to the matchExpressions with the operator NotIn will avoid scheduling the mongo pods on any node labelled role=monitoring.

Learn how to continuously optimize your k8s cluster

Nodes taints and tolerations

While nodes anti-affinity patterns allow you to prevent pods from running on specific nodes, they suffer from a drawback: the pod definition must explicitly declare that it shouldn’t run on those nodes. So, what if a new member joins the development team, writes a Deployment for her application, but forgets to exclude the monitoring nodes from the target nodes? Kubernetes administrators need a way to repel pods from nodes without having to modify every pod definition. That’s the role of taints and tolerations.

When you taint a node, it is automatically excluded from pod scheduling. When the schedule runs the predicate tests on a tainted node, they’ll fail unless the pod has toleration for that node. For example, let’s taint the monitoring node, mon01:

kubectl taint nodes mon01 role=monitoring:NoSchedule

Now, for a pod to run on this node, it must have a toleration for it. For example, the following .spec.toleration:

tolerations:
- key: "role"
  operator: "Equal"
  value: "monitoring"
  effect: "NoSchedule"

matches the key, value, and effect of the taint on mon01. This means that mon01 will pass the predicate test when the Scheduler decides whether or not it can use it for deploying this pod.

An important thing to notice, though, is that tolerations may enable a tainted node to accept a pod but it does not guarantee that this pod runs on that specific node. In other words, the tainted node mon01 will be considered as one of the candidates for running our pod. However, if another node has a higher priority score, it will be chosen instead. For situations like this, you need to combine the toleration with nodeSelector or node affinity parameters.

TL;DR

  • The Kubernetes Scheduler is the component in charge of determining which node is most suitable for running pods.
  • It does that using two main decision-making processes:
    • Predicates: which are a set of tests, each of them qualifies to true or false. A node that fails the predicate is excluded from the process.
    • Priorities: where each node is tested against some functions that give it a score. The node with the highest score is chosen for pod deployment.
  • The Kubernetes Scheduler also honors user-defined factors that affect its decision:
    • Node Selector: the .spec.nodeSelector parameter in the pod definition narrows down node selection to those having the labels defined in the nodeSelector.
    • Node affinity and anti-affinity: those are used for greater flexibility in node selection as they allow for more expressive selection criteria. Node affinity can be used to guarantee that only the matching nodes are used or only to set a preference.
  • Taints and tolerations work in the same manner as node affinity. However, their default action is to repel pods from the tainted nodes unless the pods have the necessary tolerations (which are just a key, a value, and an effect). Tolerations are often combined with node affinity or node selector parameters to guarantee that only the matched nodes are used for pod scheduling.

Announcing the CNCF Prometheus Project Journey Report

By | Blog

Today we are very excited to release our Project Journey Report for Prometheus. This is the third report we have issued for CNCF graduated projects following reports for Kubernetes and Envoy.

Prometheus is a widely-adopted open source metrics-based monitoring and alerting system. When Prometheus joined CNCF in May 2016, the foundation started promotional efforts to help sustain, nurture, and expand the Prometheus community. These efforts have included blog posts, email newsletter mentions, social media support, CNCF-hosted webinars, and end-user case studies.

Today, Prometheus is kicking off its fourth PromCon in Germany, which is sold out with more than 200 attendees. CNCF has helped administer the events in 2017, 2018, and 2019, and is working with the Prometheus maintainers to plan how the event should expand in the future including adding an event in North America.

This report attempts to objectively assess the state of the Prometheus project and how CNCF has impacted the progress and growth of Prometheus. For the report, we pulled data from multiple sources, particularly CNCF’s own DevStats tool, which provides detailed development statistics for all CNCF projects.

Some of the highlights of the report include:

  • Code Contributions – The total number of companies contributing code has increased by 258% since Prometheus joined CNCF, from 202 to 723.

Cumulative growth of contributions by company since Prometheus project launch (Q1 2014 – Q3 2019)

  • Development Velocity – Prometheus has enjoyed an 825% expansion of individual contributors over the three years since the project joined CNCF.

Cumulative growth in commits by quarter (Q1 2014 – Q3 2019)

  • Documentation – The number of documentation commits has increased by 241% since Prometheus joined CNCF.

Growth in participation in Prometheus project documentation (Q1 2014 – Q3 2019)

Since joining CNCF in 2016, Prometheus has recorded:

  • >6.3 K contributors
  • >13.5 K code commits
  • >7.2 K pull requests
  • >113 K contributions
  • 723 contributing companies

Prometheus is growing quickly – in fact, it is among the top three CNCF projects in terms of velocity. As we continue to collaborate with the project maintainers, we only expect this rapid growth to continue.

This report is part of CNCF’s commitment to fostering and sustaining an ecosystem of open source, vendor-neutral projects. Please read and enjoy the report, share your feedback with us – and stay tuned for more project journey reports for other projects.

1 2 39
